Pin |
ECU Pin |
Function |
Pin |
ECU Pin |
Function |
1 |
Ground |
|
67 |
DI 8 |
Crash Signal |
2 |
Ground |
|
68 |
Ground (O2 Sensor 2) |
|
3 |
+12V |
ECU Power |
69 |
An Volt 9 |
O2 Sensor 2 (Some) |
4 |
nc |
|
70 |
An Volt 8 |
O2 Sensor 1 |
5 |
Injector 5 (Aux) |
O2 Sensor #1 Heater |
71 |
nc |
|
6 |
nc |
|
72 |
+5V Out (APS 2) |
|
7 |
nc |
|
73 |
+5V Out (APS 1) |
|
8 |
nc |
|
74 |
nc |
|
9 |
nc |
|
75 |
nc |
|
10 |
nc |
|
76 |
nc |
|
11 |
nc |
|
77 |
nc |
|
12 |
nc |
|
78 |
nc |
|
13 |
nc |
|
79 |
nc |
|
14 |
nc |
|
80 |
nc |
|
15 |
nc |
|
81 |
nc |
|
16 |
nc |
|
82 |
Trig 1 |
Trig 1 (Crank) |
17 |
nc |
|
83 |
+5V Out (TPS) |
|
18 |
nc |
|
84 |
An Volt 4 |
TPS (Sub) |
19 |
nc |
|
85 |
An Temp 2 |
IAT |
20 |
nc |
|
86 |
Trig 2 |
Trig 2 (Cam) |
21 |
Power Relay Control |
some models only |
87 |
nc |
|
22 |
nc |
|
88 |
Injector 4 |
Injection |
23 |
nc |
|
89 |
Injector 2 |
Injection |
24 |
nc |
|
90 |
Ground (Trig 1) |
|
25 |
nc |
|
91 |
Ground (TPS) |
|
26 |
nc |
|
92 |
An Volt 3 |
TPS (Main) |
27 |
Ground (AFM) |
|
93 |
An Temp 1 |
ECT |
28 |
DI 9 |
Spare* |
94 |
Ignition 4 |
Ignition |
29 |
An Volt 2 |
AFM |
95 |
Ignition 2 |
Ignition |
30 |
nc |
|
96 |
Injector 1 |
Injection |
31 |
nc |
|
97 |
Injector 3 |
Injection |
32 |
nc |
|
98 |
+5V Out (MAP, Trig) |
|
33 |
Ground (APS 2) |
|
99 |
Ground (Knock) |
|
34 |
An Volt 6 |
APS 2 (Sub) |
100 |
nc |
|
35 |
An Volt 5 |
APS 1 (Main) |
101 |
An Volt 7 |
Intercooler Pressure |
36 |
Ground (APS 1) |
|
102 |
Ignition 1 |
Ignition |
37 |
Aux 1 |
Tacho |
103 |
Ignition 3 |
Ignition |
38 |
nc |
|
104 |
Aux 3 |
Wastegate Solenoid |
39 |
DI 4 |
Clutch |
105 |
Aux 2 |
Turbo Recirculation valve |
40 |
DI 6 |
A/C Request |
106 |
Knock 1 |
Knock |
41 |
DI 7 |
A/C Compressor State |
107 |
Knock 2 |
Knock |
42 |
nc |
|
108 |
Ground (Shield) |
|
43 |
nc (K Line) |
|
109 |
nc |
|
44 |
nc |
|
110 |
An Temp 3 |
Spare* |
45 |
nc |
|
111 |
An Volt 10 |
Spare* |
46 |
nc |
|
112 |
DI 9 |
Spare* |
47 |
|
|
113 |
Ignition 6 (Aux) |
Spare* |
48 |
Aux 7 |
CE Light |
114 |
|
|
49 |
DI 5 |
PS Switch |
115 |
Injector 6 (Aux) |
|
50 |
Ground (PS) |
|
116 |
nc |
|
51 |
Ground (O2 Sensor) |
|
117 |
Aux 9 |
E-Throttle Motor (+) |
52 |
nc |
|
118 |
Aux 10 |
E-Throttle Motor (-) |
53 |
+5V Out (AFM) |
|
119 |
nc |
|
54 |
DI 1 |
Vehicle Speed |
120 |
nc |
|
55 |
DI 2 |
Brake NC |
121 |
nc |
|
56 |
DI 3 |
Brake NO |
|
||
57 |
nc |
|
On Board MAP |
An Volt 1 |
MAP |
58 |
CAN 2 Low |
|
Expansion 1 |
Ground (Signal) |
|
59 |
nc |
|
Expansion 2 |
+5V Out |
|
60 |
CAN 2 High |
|
Expansion 3 |
An Temp 3 |
|
61 |
|
|
Expansion 4 |
An Volt 10 |
|
62 |
nc (+12V constant) |
|
Expansion 5 |
An Volt 11 |
|
63 |
Injector 7 (Aux) |
O2 Sensor #2 Heater |
Expansion 6 |
DI 10 |
|
64 |
Aux 6 |
Purge Canister |
Expansion 7 |
DI 9 |
|
65 |
Aux 5 |
Fuel Pump Relay |
Expansion 8 |
Ignition 6 (Aux) |
|
66 |
|
|
EThrottle Relay |
Aux 8 |
EThrottle Relay |
*Note: DI 9, An Temp 3, An Volt 10, Ignition 6 are also on the expansion connector.
Note: Injector Drive 8 isn't exposed and doesn't have the hardware required to drive Injectors.
