Pin |
ECU Pin |
Function |
Pin |
ECU Pin |
Function |
1 |
Ignition 3 (No Ignitor) |
spare |
66 |
Aux 9 |
E-Throttle + |
2 |
Ignition 4 (No Ignitor) |
spare |
67 |
nc |
|
3 |
Ign 1 (Internal Ignitor) |
Ignition |
68 |
nc |
|
4 |
Ign 2 (Internal Ignitor) |
Ignition |
69 |
nc |
|
5 |
Injector 5 (Aux) |
O2 Sensor #1 Heater |
70 |
nc |
|
6 |
Ground (NB Oxy 1) |
|
71 |
Ground (O2 1 Shield) |
|
7 |
Ground (Knock) |
|
72 |
Ground (Trig 2) |
|
8 |
Knock 1 |
Knock |
73 |
Ground (Cruise Control) |
|
9 |
An Volt 7 |
O2 Sensor #1 |
74 |
Ground (Trig 1) |
|
10 |
An Volt 5 |
Throttle Position #A |
75 |
nc |
|
11 |
An Volt 6 |
Throttle Position #B |
76 |
nc |
|
12 |
Ground (TPS) |
|
77 |
nc |
|
13 |
+5V Out (TPS) |
|
78 |
nc |
|
14 |
nc |
|
79 |
nc |
|
15 |
nc |
|
80 |
Ground |
|
16 |
nc |
|
81 |
Ground |
|
17 |
nc |
|
82 |
+5V Out (APS A) |
|
18 |
nc |
|
83 |
+5V Out (APS B) |
|
19 |
Injector 4 |
Injection |
84 |
nc |
|
20 |
Injector 2 |
Injection |
85 |
DI 3 |
Clutch Switch |
21 |
Injector 1 |
Injection |
86 |
Ground (APS A) |
|
22 |
Injector 3 |
Injection |
87 |
Ground (APS B) |
|
23 |
nc |
|
88 |
Ignition 6 (Aux) |
Engine Fan |
24 |
Aux 3 |
Purge Solenoid |
89 |
nc |
|
25 |
An Temp 3 |
Transmission Oil |
90 |
An Volt 9 |
A/C Pressure |
26 |
An Temp 1 |
ECT |
91 |
+5V Out (AC Pressure) |
|
27 |
An Temp 2 |
IAT |
92 |
nc |
|
28 |
nc |
|
93 |
DI 10 |
Leak Diag Pump Switch |
29 |
An Volt 2 |
MAP - Pre Supercharger |
94 |
Aux 6 |
A/C compressor Relay |
30 |
nc |
|
95 |
Ignition 7 (Aux) |
Engine Fan 2 |
31 |
An Volt 1 |
MAP - Post Supercharger |
96 |
Aux 5 |
Gear Shift Interlock |
32 |
nc |
|
97 |
Main Relay Control |
|
33 |
nc |
|
98 |
DI 4 |
Brake Light Switch |
34 |
nc |
|
99 |
DI 5 |
Brake Light Switch Test |
35 |
nc |
|
100 |
Ground (AC Pressure) |
|
36 |
nc |
|
101 |
DI 6 |
Steering Wheel Button Pad |
37 |
nc |
|
102 |
nc |
|
38 |
nc |
|
103 |
nc |
|
39 |
nc |
|
104 |
nc |
|
40 |
nc |
|
105 |
Ignition 5 (Aux) |
Fuel Pump Relay |
41 |
nc |
|
106 |
|
|
42 |
Aux 2 |
Leak Diag Pump Solenoid |
107 |
An Volt 4 |
APS Position #B |
43 |
Injector 6 (Aux) |
O2 Sensor #2 Heater |
108 |
An Volt 3 |
APS Position #A |
44 |
nc |
|
109 |
An Volt 8 |
O2 Sensor #2 |
45 |
Ground (Trans Oil Temp) |
|
110 |
CANH2 |
|
46 |
Ground (ECT) |
|
111 |
CANL2 |
|
47 |
Ground (MAP/IAT) |
|
112 |
Ground (NB Oxy 2) |
|
48 |
Ground(Knock Shield) |
|
113 |
DI7 |
OBD2 Plug (Pin 9) |
49 |
nc |
|
114 |
Ground |
|
50 |
nc |
|
115 |
Ground |
|
51 |
+5V Out (MAP) |
|
116 |
nc |
|
52 |
DI 1 |
Alternator Load |
117 |
nc |
|
53 |
Trig 2 |
Trig 2 |
118 |
Ignition Switch |
Controls Main Relay |
54 |
DI 2 |
Cruise Control PWM |
119 |
nc |
|
55 |
Trig 1 |
Trig 1 |
120 |
+14V |
ECU Power |
56 |
nc |
|
121 |
nc (Constant 12V) |
|
57 |
nc |
|
|
||
58 |
nc |
|
|||
59 |
nc |
|
Expansion 1 |
Ground (Signal) |
|
60 |
nc |
|
Expansion 3 |
An Volt 11 |
|
61 |
Ground |
|
Expansion 4 |
An Volt 10 |
|
62 |
Ground |
|
Expansion 5 |
An Temp 4 |
|
63 |
Aux 10 |
E-Throttle - |
Expansion 6 |
DI 9 |
|
64 |
Aux 10 |
E-Throttle - |
Expansion 7 |
DI 8 |
|
65 |
Aux 9 |
E-Throttle + |
Expansion 8 |
Aux 1 |
|
Note: Injector Drives 7 and 8 aren't exposed and don't have the hardware required to drive Injectors.
