GM throttle body settings |
|
Frequency |
500 Hz |
Deadband |
0.1% |
Proportional Gain |
7.00 |
Integral Gain |
0.051 |
Derivative Gain |
35.00 |
Max Clamp |
90.0% DC |
Min Clamp |
-90.0 % DC |
Wiring Information > Input Signal Wiring > Analog Inputs > Throttle/Accelerator Position Sensors > Specific TPS/APS Applications > GM Throttle body
